Digital signage is only as useful as the content on the screen. Black Box iCOMPEL® Content Commander appliance (iCC) empowers everyone in your organization to create, distribute and manage the content that helps meet business goals. The iCC balances ease of use for novices with access to more powerful features for experts. With this comprehensive platform, users can achieve any organizational goals — brand engagement, increased revenue, industry compliance, increased efficiencies, awareness, cost reduction, customer satisfaction — or any combination.
Create compelling content
- Easy-to-use multilingual web user interface.
- Unlimited number of screen layout zones in any position, layer, and time.
- Drag-and-drop user interface lets users from throughout your organization create compelling content with minimal training.
- Preview content in the browser.
- Incorporate RSS feeds, social media updates and live TV.
- Reuse Web assets for dynamic, informational signage with web page crop and zoom.
- Variable transparency for content and layout zones.
- Independent background audio capability.
Schedule for maximum impact
- Deliver the right message in the right place at the right time.
- iCC makes it easy to taret a specific audience through scheduled playlists, so you can serve relevant content at particular times of day.
- Folder play for sub playlists of content.
- Conditional playback based on player tagging.
- Content triggering (advance to/rendezvous).
Distribute to any player
- iCC provides for multi-user management of multiple content channels.
- Content distribution to players supports USB, wired, WiFi, 3G, or satellite connections.
- Supports manual and automatic publishing.
- Up to 250 simultaneous subscribers.
Manage the network
- Player alerts communicate problems to the administrator.
- Live screen shots.
- Pick Player Local Information from a stored list instead of typing in values each time a piece of content is set up to a different location.
- License management.
- Easy filtering/selection by naming of tags.
Make it local
- The Web-based user interfaces make it simple to manage local ("ad hoc") messages and data, such as menus and venue schedules.
- Pre-designed, simplified and branded ad hoc user interfaces.
- Designed for the novice or occasional user, ad hoc portals are easy to use Web-browser based interfaces through which users can adage local messages.
- Instant messaging to a single player or a group of players.
- Local uploading of media for automatic playback according to pre-defined rules.
Approval — CE, UL, RoHs
CPU Processor — Intel Haswell i5 4590T CPU
Media Sources —
Hard disc: All media types;
Ethernet: MPEG-TS, UDP, IP streaming (optional);
Internet: HTML (Web pages), RSS feeds (with multilingual support), XML files
Network Interfaces — Ethernet: 10/100/1000 BaseT
Storage —
System RAM: 16GB;
System Media Storage: 1TB hard drive disc (HDD)
Power— Internal PSU 100-240 VAC 50/60 Hz, consumption 60W
Size — 28H x 27W x 7.7D cm (11"H x 10.6"W x 3"D)
Weight— 4 kg
TAA compliant — YES
(1) iCOMPEL® Appliance
Licensing for 25,50,100, or 250 users
(1) Power cord
(1) Open source CD
(1) Quick Start Guide
|
|
