Video Extenders
Compare models and choose the right option for you
Our video extenders comparison table helps you identify the key differences between our HDMI, DisplayPort, DVI, VGA and SDI/analogue video extenders so you can pick the right system depending on the requirements for your installation and your project budget.
Maximize your signal reach without the need for expensive new cabling, and deliver pixel-perfect video to remote displays. Black Box extenders are guaranteed to bring you the flexibility and scalability you need to transmit video with or without audio and control signals over the distance for point-to-point extensions or networked digital signage settings.
Give your HD video a boost by extending it over CATx or fibre optic cable. Using current infrastructure saves time and money. Sending video signals over fibre means, they can travel long distances with the added benefit of optical isolation and noise immunity.
With Black Box's Video Extenders, you can extend any video signal through dedicated wires or even over a network. Browse our Black Box Video Extenders alternatives and efficiently extend the reach of your installations and future-proof your system.
HDMI Extenders
Display HDMI audio/video on remote displays with crystal-clear images. Select your model depending on your required range, resolution and signal set.
Distance up to
Video Support
IR
RS232/
Control
USB
Ethernet
Power to receiver
Part Number
HDMI cable
35m
1080p
VR-HDMI-50M
CATx
50m
1080p
•
AVU8010A
60m
1080p, 3D, HDCP
VX-HDMI-TP-3D40M
40m/70m
4K/1080p
•
•
•
VX-HDB-KIT
40m/70m
4K/1080p
•
•
VX-HDB-RX
40m/70m
4K/1080p
•
•
•
VX-HDB-TX
40m/70m
4K/1080p
•
•
•
AVX-HDMI2-HDB-KIT
70m
4K HDCP
•
VX-HDMI-TP-70M
100m
1080p, 3D, HDCP
•
•
VX-HDMI-TP-100M
100m
4K HDCP
•
•
•
•
•
VX-1001-RX
Multimode
300m
4K/60 4:4:4
•
•
AVX-HDMI2-FO-HDB-KIT
2km
1080p, 3D, HDCP
VX-HDMI-FO
IP
100m per segment
1080p
•
VX-HDMI-HDIP-RX
100m per segment
4K
•
VX-HDMI-4KIP-RX
IP H.264
100m per segment
1080p
VS-2000-ENC
IP SDVoE
100m CATx
4K/60, 4:4:4
•
•
MCX-S7-ENC
100m CATx
4K/60, 4:4:4
•
•
MCX-S7-DEC
100m CATx
4K/60, 4:4:4, Scaling
•
•
•
MCX-S9-ENC
100m CATx
4K/60, 4:4:4, Scaling
•
•
•
MCX-S9-DEC
100m CATx/FO
4K/60, 4:4:4, Scaling
•
•
MCX-S9C-ENC
100m CATx/FO
4K/60, 4:4:4, Scaling
•
•
MCX-S9C-DEC
100m CATx/FO
4K/60 4096x2160 @ 60 Hz
•
•
•
MCX-S9D-ENC
DisplayPort Extenders
Reach distant screens with our 4K DisplayPort 1.2 extenders.
Distance up to
Video Support
Audio
RS232/ Control
USB
Ethernet
PoE to receiver
Part Number
HDBaseT
100m
4K, HDCP
•
•
•
UVX-DP-TP-100M
SDVoE
100m CATx/FO
4K/60, 4:4:4, HDCP
•
•
MCX-S9C-ENC
100m CATx/FO
4K/60, 4:4:4, HDCP
•
•
MCX-S9C-DEC
DVI Extenders
Need to connect a local DVI source to a remote Full HD display? Select from our wide DVI extender offer extending Single Link DVI or Dual Link DVI with or without audio and control signals over CATx or Fibre.
Distance up to
Video Support
Audio
RS232/ Control
Line/IC powered receiver
Part Number
DVI cable
27m
1920x1200
VR-DVI
CATx
50m
1600x1024
ACS2001A-R3
50m
1920x1200
•
AVU8011A
100m
1920x1200
•
•
AVX-DVITP-100M
Fibre
1500m
1920x1200
•
•
•
AVX-DVI-FO-MINI
750m
1920x1200
•
AC1037A-MM
VGA Extenders
Use our VGA extenders if you need to transmit VGA-signals (and audio) to distant displays. With our videos extenders you are guaranteed to have high quality video processing through EDID-management and DeSkew functions.
Distance up to
Video Support
Audio
RS232
Scalable to distribution system
Line/IC powered receiver
Part Number
CATx
150m
1024x768
•
AC555A-R2
150m
1600x1200
•
•
AC504A
150m
1920x1200
•
AVU4001A
150m
1920x1200
•
VX-VGA520-K
300m
1280x1024
•
•
AVU5001A
300m
1920x1200
•
•
•
AVU6001A
300m
1920x1200
•
•
•
AVX-VGA-TP-TX
Fibre
30km
1080i
•
AC1020A
SDI/Analogue Extenders
Need to extend high quality SDI video for remote monitors in broadcast applications? Want to show the content from HDTV-sources on far off screens? Here are the solutions for you.
Distance up to
Video Support
SDI
Analogue Video
Audio
Part Number
CATx
100m
3G
•
•
IC800A
Fibre
2.4km
PAL,Secam,NTSC
•
AC444AE
Video FiberPath Sends video in color or black and white up to 1.5 miles (2.4 km). Operates over standard simplex multimode fiber optic cable. Ideal for long-distance information displays, signs, and security systems. Compatible with all standard video formats, including NTSC, PAL, and SECAM. Eliminates ground-loop problems. Immune to electrical interference. Easy to install; all you need is a screwdriver. Sign in to view prices
VGA Extender & Splitter - Wizard MM Flexible, affordable, high quality AV distribution. Optimised for digital signage applications. Crystal clear Video +high fidelity audio at 300m. Ideal for retail, waiting rooms and much more. Don't forget to order input cables when you order transmitters. See Accessoires below for our suggestions. Sign in to view prices
Wizard MM Extender & Splitter Plus Ideal for digital signage applications, inretail outlets, airports, corporate environments and more. Resolutions up to 1920 x 1200 supported. Image compensation for crystal clear video and audio to 300m. RS-232 connectivity enabling control of individual or multiple displays. Scalable up to 64 outputs. Sign in to view prices
CATx VGA Extender Extend VGA video up to 500 feet (152.4 m) on ordinary CAT5, CAT5e, or CAT6 cable. Ideal for digital signage applications, such as exhibits, retail, trade shows, and airports. Has a 2-kV avalanche diode, which provides greater electrostatic discharge (ESD) protection and more reliable operation. An equalization (gain) control on the remote unit enables you to fine-tune the picture. Sign in to view prices
CATx DVI-D Single Link Extender Cost-effective, high-quality extension of Single Link DVI-D video over one CATx cable. Resolutions up to 1920x1200/60 Hz at 30m Resolutions up to 1920x1080/60 Hz at 35m Resolutions up to 1600x1200/60 Hz at 50m True DDC read channel. internal power protection assures a continuous and steady video signal. Ultra compact for discrete plag-and-play installation. Sign in to view prices
3D HDMI Fiber Extender Extend a video signal up to 2 km (1.2 miles) at 1080i or 1 km (0.6 miles) at 1080p via multimode fiber cable. Pure digital transmission with zero compression. Fully compliant with HDMI 1.3b specification. HDCP compliant and Blu-ray ready. No software or driver installation required. Fiber optics ensure noise immunity and a high level of security. IR extending function available. Sign in to view prices
XR HDMI and IR Extender Uses a single CAT5e/6 run. Extends uncompressed HD video, audio, and control signals up to 100m. Supports IR extension with CEC passthrough. Control source devices at the screen. Great video capacity and 3D support. Provides 10.2 Gbps of HDMI video bandwidth on all channels. Supports 1080p video at 60 Hz and 48-bit pixel rates. HDCP compliant and Blu-ray ready. No software or driver installation required. Wall mountable for space-saving installation. Sign in to view prices
Mini CATx VGA Extender Kit Extends VGA video up to 150m over ordinary CAT5/5e/6 cable. Requires only a single power supply unit. Can be powered conveniently from either end of the CATx link, locally or remotely. Eliminates the need for bulky VGA cables, allowing you to use UTP cable already installed. Features video equalization adjustment for optimizing image quality at maximum distances. Supports VGA resolutions up to 1920 x 1200, including 1080p quality video. The kit includes a transmitter, receiver, and power supply. Very compact, standalone units for space-saving installation. Sign in to view prices
XR DVI-D Extender with Audio, RS-232, and HDCP Use a single CAT5e/6/7 run for extending DVI-D video plus audio. Also extends RS-232 and HDCP signals to the remote screen. Goes much farther than standard DVI cabling—up to 100m*. Supports resolutions up to 1080p (HDTV) or 1920 x 1200 (VESA). Enables flexible screen location without compromising video quality. HDCP compliant and Blu-ray ready, and supports EDID. Transmits serial RS-232 TXD and RXD control signals. Sign in to view prices
MediaCento VX Use ordinary CATx cable instead of expensive VGA cable to extend high-quality multimedia. Broadcasts high-quality VGA plus audio and serial signals over standard UTP cabling. Features an icon-based GUI for easily managing the system. Supports VGA resolutions up to 1920 x 1200 (or 1920 x 1080). Extends video up to 300 m (long range receiver) or more than 600m with cascadable receivers. Long-range receivers feature advanced skew compensation, sharpness, and brightness controls. Local video and audio ports for plugging in a monitor and speakers at the source. Enables independently turning on/off of video and audio ports. Automatically detects and indicates signal from the video source. EDID copy function for optimal PC-to-screen performance. 3.5-mm stereo jacks for audio and speaker connections. For serial device extensions, transmits RS-232 (TX/GND) signals. Sign in to view prices
Line-Powered Video Extender - HDMI over CATx Reach up to 50m over a single shielded CATx cable. Smart EDID management keeps aspect ratios and resolutions intact indiscriminate of display type. This ensures the correct content is displayed. Durable locking connectors to ensure strong connectivity. Digitally transmit high-fidelity 16, 20, or 24 bit stereo audio. The HDMI over CATx Line-Powered Extender Kit supports eight channels of HDMI audio. Built to last and selected for reliability, durability, and performance. Sign in to view prices
Line-Powered Extender Kit - DVI over CATx Easy-to-install, plug-and-play system gets you connected right away. The uncompressed communication system allows for crisp, digital video delivery with resolutions up to 1920x1200 at 60Hz. Reach up to 50m over a single shielded CATx cable. Smart EDID management keeps aspect ratios and resolutions intact indiscriminate of display type. This ensures the correct content is displayed. Durable locking connectors to ensure strong connectivity. Built to last and selected for reliability, durability, and performance. Sign in to view prices
4K HDMI IR Extender 70M Send HDMI signals to multimedia displays up to 70 m using a single CAT5e/6 cable. Resolutions up to 1080p @70m or 4k@ 40m with lossless compression. This kit includes an HDMI transmitter and HDMI receiver. Sign in to view prices
3G-SDI Extender Kit Transmits uncompressed, unencrypted digital video point-to-point up to 100m at 3G-SDI speeds of 2.97/3.0 Gbps. Use within television facilities and between professional video equipment. Easy to install—just plug-and-play. Requires a source signal from a PC or media player and amplifies it to reach the sink (speaker system). Send 3G-SDI digital video up to 100m over twisted-pair cable. Optionally includes embedded audio and/or time code. Use for broadcast, commericial and residential AV systems, classroom projector systems, digital signage, and boardroom systems. Requires a source signal from a PC or media player and amplifies it to reach the sink (speaker system). Kit includes one transmitter and one receiver. Sign in to view prices
4K HDMI CATx Extender USB - VX1000-Series Supports up to 4K (UHD) resolutions. Reliable connection with highest video quality. True 48V PoC powering only requires a single power supply. USB support for keyboard and mouse. Automatic HDMI EDID management. HDCP 2.2 compliance. RS-232 and Ethernet pass-through. All connections on the same side of device. Works with 4 x 1 and 8 x 2 Presentation Switchers (AVSC-0401H-R2, AVSC-0802H). Sign in to view prices
A/V Extender – 4K DisplayPort, Audio, USB 2.0 & RS232 USB 2.0 passthrough Use 48 V PoC (Power over CATx) to power the receiver unit from the transmitter HDCP 2.2 compliant and supports EDID transmission Extend your signals as far as 100m over CAT6A/CAT7 cables Transmitting uncompressed video, native 4K@30 Hz UHD DisplayPort signals Supports resolutions up to 4K, including 3840 x 2160 and 1080p/60 Deep Color Access distant AV sources or even to control remote computers Simultaneously transmits bidirectional analog stereo audio Sign in to view prices
HDMI-over-IP Extender MediaCento IPX 4K, USB Audio Serial IR Supports up to 4K UHD 4096 x 2160 @ 30Hz and 1920 x 1200 @ 60Hz and all 3D formats Supports digital and analog audio embedding and extraction 4K to 1080p downscaling USB 2.0, bi-directional IR and serial Any source to any screen over IP Extend HDMI video and audio signals over a Gb Ethernet network Create video walls up to 8x8 displays USB 2.0 and USB HID support supports touchscreens and KVM capabilities PoE power eliminates external power supplies Maximum latency 2 frames or 33ms Sign in to view prices
HDMI-over-IP Extender MediaCento IPX HD Supports up to 1080p HD Setup units using only the front panel interface, no additional configuration required Intercompatible with the MediaCento 4k Any source to any screen, over IP Extend HDMI video signals over a Gigabit Ethernet network Create eye-catching video walls of up to 8x8 displays PoE power eliminates external power supplies Use with the MediaCento Controller for matrix switching and video wall control Maximum latency 2 frames or 33ms Sign in to view prices
HDMI Extender CATx – 4K/1080p HDMI 1.4, PoC, IR, RS232, 70m Delivers a high-resolution image: 1080p @ 60 Hz @ 48 b/pixels/3D/4K x 2K Max. distance: 40 meters for 4K x 2K or up to 70m for 1080p over a single CATx cable High-bandwidth: 10.2 Gbps HDTV compatible HDMI 1.4 and HDCP 2.2 compliant Supports bidirectional PoC (Power over CATx) only one unit requires power supply Transmit audio/video, IR, serial control data, and power over a single CATx cable LED indicators show work status Sign in to view prices
HDMI 2.0 Extender over CATx HDCP 2.2 compliant HD signal transmission via a single CAT5e/CAT6 cable up to 100 m (1080p) and 70 m (4K at 60 Hz YUV 4:4:4) HD signal transmission via a single CAT6A/7 cable up to 100 m (1080p) and 100 m (4K at 60 Hz YUV 4:4:4) IR pass-through allows you to control the source from the display location or control the display from the source location Use two RS-232 control systems for serial communication by connecting to the devices via serial cables to control the source device or display Sign in to view prices
HDMI 2.0 Extender over Fiber Supports up to 4K @ 60 4:4:4 8 bit HDMI signal transmission. Locking HDMI ports prevent accidental cable disconnections. HDCP 2.2 compliant. Supports HDR. Transmits 4K @ 60 4:4:4 signals up to 300m over multimode OM3 cable with 10 Gbps multimode. SFP+ modules (SFP+ modules are included). Video transmission is compressed when the data rate is above 3 Gbps (e.g. 4K @ 60 Hz 4:4:4). Supports bi-directional IR or RS232 passthrough to allow different types of displays or sources. Multichannel audio supports up to PCM 7.1, DTS Master HD and Dolby True HD. Locking DC power plugs. Sign in to view prices
MCX S7 4K60 Network AV Encoder or Decoder - HDMI 2.0, HDCP 2.2, 10-GbE Copper True 4K 60 Hz 4:4:4 video and uncompressed 10-bit HDR. Supports HDMI 2.0 over IP. Zero source to display latency. Seamless switching with no artifacts or screen blink. Intuitive control through MCX Web UI. Seamless matrix switch capability. Sign in to view prices
MCX S9 4K60 Network AV Decoder - HDMI 2.0, Scaling, USB, 10-GbE Copper or Fiber True 4K 60 Hz 4:4:4 video and uncompressed 10-bit HDR. Distributes AV, Ethernet and peripheral signals over an Ethernet network Zero source to display latency. Seamless switching with no artifacts or screen blink. Intuitive control through MCX Web UI. Advanced scaling options like multi-view, pip and more for video walls. Sign in to view prices
HDMI Extender CATx – 4K/1080p HDMI 1.4, PoC, IR, RS232, 70m Delivers a high-resolution image: 1080p @ 60 Hz @ 48 b/pixels/3D/4K x 2K Max. distance: 40 meters for 4K x 2K or up to 70m for 1080p over a single CATx cable High-bandwidth: 10.2 Gbps HDTV compatible HDMI 1.4 and HDCP 2.2 compliant Supports bidirectional PoC (Power over CATx) only one unit requires power supply Transmit audio/video, IR, serial control data, and power over a single CATx cable LED indicators show work status Sign in to view prices
MCX S7 4K60 Network AV Encoder or Decoder - HDMI 2.0, HDCP 2.2, 10-GbE Copper True 4K 60 Hz 4:4:4 video and uncompressed 10-bit HDR. Supports HDMI 2.0 over IP. Zero source to display latency. Seamless switching with no artifacts or screen blink. Intuitive control through MCX Web UI. Seamless matrix switch capability. Sign in to view prices
MCX S9 4K60 Network AV Decoder - HDMI 2.0, Scaling, USB, 10-GbE Copper or Fiber True 4K 60 Hz 4:4:4 video and uncompressed 10-bit HDR. Distributes AV, Ethernet and peripheral signals over an Ethernet network Zero source to display latency. Seamless switching with no artifacts or screen blink. Intuitive control through MCX Web UI. Advanced scaling options like multi-view, pip and more for video walls. Sign in to view prices
HDMI Extender CATx – 4K/1080p HDMI 1.4, PoC, IR, RS232, 70m Delivers a high-resolution image: 1080p @ 60 Hz @ 48 b/pixels/3D/4K x 2K Max. distance: 40 meters for 4K x 2K or up to 70m for 1080p over a single CATx cable High-bandwidth: 10.2 Gbps HDTV compatible HDMI 1.4 and HDCP 2.2 compliant Supports bidirectional PoC (Power over CATx) only one unit requires power supply Transmit audio/video, IR, serial control data, and power over a single CATx cable LED indicators show work status Sign in to view prices
