Video Switches
Compare models and choose the right option for you
Managing video signal distribution should be easy, that's why our solutions allow you to easily switch one or multiple video sources between one or more screens.
Discover our wide selection of video switches and choose the most suitable video switches for easy video signal distribution.
Set up video distribution systems to deploy digital signage, enhance presentations, and extend HD video beyond the boardroom.
Select from an assortment of video switchers for multiple input/output configurations. Available in multiple form factors (single output or matrix), video formats and resolution capabilities.
Switch one AV source between several displays
Control an array of AV signals with flexibility and simplicity
Route AV signals from multiple sources to one or more displays
HDMI Switches
Display HDMI audio/video on multiple displays with crystal-clear images. Select your model depending on the number of required sources/displays and control options
Control
HDMI
In-/ Outputs
Max. Res.
HDCP
Extra Audio Outputs
Serial
IR
IP
Extras
SKU
HDMI 2.0
4x4
4K
2.2
•
•
•
•
3D
AVS-HDMI2-4x4
HDMI 2.0
8x8
4K
2.2
•
•
•
•
3D
AVS-HDMI2-8x8
HDMI 1.3
2x1
4K/30 UHD
1.1
•
•
3D
VSW-HDMI2X1-4K
HDMI 2.0
3x1
4K/60 UHD
2.2
•
VSW-HDMI2-3X1
HDMI 1.3
4x1
4K/30 UHD
1.1
•
•
3D
VSW-HDMI4X1-4K
HDMI 1.4
2x2
4K/30 UHD
2.0
•
•
3D
VSW-HDMI2X2-4K
HDMI 1.4
4x2
4K/30 UHD
2.0
•
•
3D
VSW-HDMI4X2-4K
HDMI 2.0
8x2
4K
2.2
•
•
•
AVSC-HDMI2-8x2
HDMI 1.4/ DVI, VGA
8x2
4K/30 UHD
1.4
•
•
incl. scaling
AVSC-0802H
HDMI 1.4/ DVI, VGA
12x4
4K/60 UHD
•
•
•
•
•
Modular
AVS-1600-R2
DisplayPort Switches
Show the audio/video from multiple DisplayPort sources on one high-resolution screen. Choose your model depending on the required number of sources and control options.
Control
DisplayPort
In-/Outputs
Max. Resolution
HDCP
Extra Audio Outputs
Serial
IR
SKU
Displayport
8x2
1080p / 1920x1200
2.2
•
•
AVSC-HDMI2-8x2
DVI Switches
Switch between multiple sources and display DVI video with or without audio on your full HD DVI-screen.
Control
In-/Outputs
Max. Resolution
HDCP
Extra Audio Outputs
Serial
IR
SKU
4x1
1920x1200
•
•
•
•
AVSW-DVI4X1
4x1
1920x1200
•
•
•
AVSC-0401H
8x2
1920x1200
•
•
•
AVSC-0802H
8x1
1920x1200
•
•
•
•
AVSW-DVI8X1
2x1
1600x1200
•
•
•
AC1032A-2A
4x1
1600x1200
•
•
•
AC1032A-4A
VGA Switches
Choose from a variety of standard or matrix video switches with a variety of control and extension options. These VGA video switches grant crystal-clear video and a reliable operation.
Control
In-/Outputs
Max. Resolution
Extra Audio Outputs
Serial
IR
Extras
SKU
2x1
1600x1200
•
video extension
AC505A
2x1
1600x1200
•
•
video extension
AC505A-2A-R2
4x1
1600x1200
•
video extension
AC506A
4x1
1600x1200
•
•
video extension
AC506A-4A
4x1
1920x1440
•
•
•
AVSW-VGA-4X1A
8x1
1920x1440
•
•
•
AVSW-VGA-8X1A
8x2
1920x1200
•
•
video extension
AVSC-0802H
8x2
1920x1200
•
•
AVSC-HDMI2-8x2
12x4
1920x1200
•
•
•
Modular
AVS-1600-R2
24x8
1920x1200
•
•
•
Modular
AVS-3200-R2
VGA Switches with Serial and Audio Route video plus audio from multiple sources to a single display. Provides high-resolution output, up to 1920 x 1200 and 1920 x 1440 VGA resolutions, as well as Full HD 1080p (1920 x 1080). Easy to set up and use with front-panel push button switching control. Also supports serial switching control plus control with the included IR R/C. Works with an array of VGA, SVGA, and multisync monitors. LEDs show your selected VGA input source. Rack mountable, Hardware included. Sign in to view prices
DVI Switch with Audio Use to quickly route video plus audio from four or eight sources to a common display. Supports Full HD 1080p/1920 x 1200 resolutions (DVI-D only). HDCP compliant and Blu-ray ready. Easy to control from the front panel, the included IR remote controller, or an RS-232 workstation. LEDs indicate the status of DVI and audio input sources. Offers full, transparent DDC support. Sign in to view prices
HDMI 4K Switch Supports up to 4K/30 resolution (UHD 3840 x 2160). Mandatory 3D-video, HDCP compliant, and Blu-ray ready. Smart auto switching function that enables device to automatically switch to a source when it becomes active. Switch between two or four different HDMI sources to a single display. Advanced EDID functionality ensures accurate output display. Control via front panel push buttons, IR remote control, serial connection. Sign in to view prices
4K HDMI Matrix Switch Supports 4K video. Switch high-resolution video plus audio from two or four sources to two displays in any combination. Control from the front panel, with the included IR remote controller. Send digital signals to any or all outputs simultaneously. Sign in to view prices
8x2 Video Matrix Switcher, 18G Seamless Switching, HDMI 2.0 Share multiple sources with two displays. HDMI 2.0 and HDCP 2.2 compliant. The video resolution can be up to 4K @ 60 Hz 4:4:4. Supports video resolution down-scaling and up-scaling, 1080p, 1920 x 1200p, 4K @ 30 Hz, 4K @ 60 Hz can be selected for HDMI and CATx outputs. Supports automatic switching. Features a mirrored HDMI output for CATx output. Visually lossless video de-compression and compression for HDMI signals transmission up to 40m at 4K and 70m at 1080p on CATx input and output. CATx input and output support 24V PoC (Power over CAT6). External balanced audio inputs can be embedded in one CATx input and two HDMI video inputs respectively. Provides two groups of audio outputs (balanced audio and digital SPDIF audio) for audio de-embedding. Supports MIX audio input and its volume control. Supports HDMI output, CATx output audio control. Multiple control options: Controllable via RS-232 local and pass-through, IR local and pass-through, TCP/IP, relay, CEC and on OSD. Sign in to view prices
Modular Matrix Switcher – 4K Seamless, I/O Auto Detect, 16-Port Comprehensive signal card compatibility: HDMI/DVI/CATx Extension. Automatically recognizes input/output signal cards. Powerful EDID management. UPnP enables quick-connection to GUI. HDCP Compliant. Controllable via front panel buttons, IR, RS-232 and TCP/IP. Adjustable output resolution. Online firmware upgrade via USB port. Sign in to view prices
HDMI 2.0 4K Video Switch - 3x1 / 4X1 3 or 4-to-1 HDMI switching for UHD video Fully compliant with HDMI 2.0 and HDCP 2.2 HDMI inputs and output support resolutions up to 4K @ 60 Hz 4:4:4 8-bit Supports top panel button, IR remote, and automatic switch control options Compact size Supports locking HDMI cables to prevent accidental cable disconnections CE, FCC, IC, RCM, and VCCI approvals Sign in to view prices
VGA Switches with Serial and Audio Route video plus audio from multiple sources to a single display. Provides high-resolution output, up to 1920 x 1200 and 1920 x 1440 VGA resolutions, as well as Full HD 1080p (1920 x 1080). Easy to set up and use with front-panel push button switching control. Also supports serial switching control plus control with the included IR R/C. Works with an array of VGA, SVGA, and multisync monitors. LEDs show your selected VGA input source. Rack mountable, Hardware included. Sign in to view prices
DVI Switch with Audio Use to quickly route video plus audio from four or eight sources to a common display. Supports Full HD 1080p/1920 x 1200 resolutions (DVI-D only). HDCP compliant and Blu-ray ready. Easy to control from the front panel, the included IR remote controller, or an RS-232 workstation. LEDs indicate the status of DVI and audio input sources. Offers full, transparent DDC support. Sign in to view prices
HDMI 4K Switch Supports up to 4K/30 resolution (UHD 3840 x 2160). Mandatory 3D-video, HDCP compliant, and Blu-ray ready. Smart auto switching function that enables device to automatically switch to a source when it becomes active. Switch between two or four different HDMI sources to a single display. Advanced EDID functionality ensures accurate output display. Control via front panel push buttons, IR remote control, serial connection. Sign in to view prices
4K HDMI Matrix Switch Supports 4K video. Switch high-resolution video plus audio from two or four sources to two displays in any combination. Control from the front panel, with the included IR remote controller. Send digital signals to any or all outputs simultaneously. Sign in to view prices
8x2 Video Matrix Switcher, 18G Seamless Switching, HDMI 2.0 Share multiple sources with two displays. HDMI 2.0 and HDCP 2.2 compliant. The video resolution can be up to 4K @ 60 Hz 4:4:4. Supports video resolution down-scaling and up-scaling, 1080p, 1920 x 1200p, 4K @ 30 Hz, 4K @ 60 Hz can be selected for HDMI and CATx outputs. Supports automatic switching. Features a mirrored HDMI output for CATx output. Visually lossless video de-compression and compression for HDMI signals transmission up to 40m at 4K and 70m at 1080p on CATx input and output. CATx input and output support 24V PoC (Power over CAT6). External balanced audio inputs can be embedded in one CATx input and two HDMI video inputs respectively. Provides two groups of audio outputs (balanced audio and digital SPDIF audio) for audio de-embedding. Supports MIX audio input and its volume control. Supports HDMI output, CATx output audio control. Multiple control options: Controllable via RS-232 local and pass-through, IR local and pass-through, TCP/IP, relay, CEC and on OSD. Sign in to view prices
Modular Matrix Switcher – 4K Seamless, I/O Auto Detect, 16-Port Comprehensive signal card compatibility: HDMI/DVI/CATx Extension. Automatically recognizes input/output signal cards. Powerful EDID management. UPnP enables quick-connection to GUI. HDCP Compliant. Controllable via front panel buttons, IR, RS-232 and TCP/IP. Adjustable output resolution. Online firmware upgrade via USB port. Sign in to view prices
8x2 Video Matrix Switcher, 18G Seamless Switching, HDMI 2.0 Share multiple sources with two displays. HDMI 2.0 and HDCP 2.2 compliant. The video resolution can be up to 4K @ 60 Hz 4:4:4. Supports video resolution down-scaling and up-scaling, 1080p, 1920 x 1200p, 4K @ 30 Hz, 4K @ 60 Hz can be selected for HDMI and CATx outputs. Supports automatic switching. Features a mirrored HDMI output for CATx output. Visually lossless video de-compression and compression for HDMI signals transmission up to 40m at 4K and 70m at 1080p on CATx input and output. CATx input and output support 24V PoC (Power over CAT6). External balanced audio inputs can be embedded in one CATx input and two HDMI video inputs respectively. Provides two groups of audio outputs (balanced audio and digital SPDIF audio) for audio de-embedding. Supports MIX audio input and its volume control. Supports HDMI output, CATx output audio control. Multiple control options: Controllable via RS-232 local and pass-through, IR local and pass-through, TCP/IP, relay, CEC and on OSD. Sign in to view prices
Modular Matrix Switcher – 4K Seamless, I/O Auto Detect, 16-Port Comprehensive signal card compatibility: HDMI/DVI/CATx Extension. Automatically recognizes input/output signal cards. Powerful EDID management. UPnP enables quick-connection to GUI. HDCP Compliant. Controllable via front panel buttons, IR, RS-232 and TCP/IP. Adjustable output resolution. Online firmware upgrade via USB port. Sign in to view prices
8x2 Video Matrix Switcher, 18G Seamless Switching, HDMI 2.0 Share multiple sources with two displays. HDMI 2.0 and HDCP 2.2 compliant. The video resolution can be up to 4K @ 60 Hz 4:4:4. Supports video resolution down-scaling and up-scaling, 1080p, 1920 x 1200p, 4K @ 30 Hz, 4K @ 60 Hz can be selected for HDMI and CATx outputs. Supports automatic switching. Features a mirrored HDMI output for CATx output. Visually lossless video de-compression and compression for HDMI signals transmission up to 40m at 4K and 70m at 1080p on CATx input and output. CATx input and output support 24V PoC (Power over CAT6). External balanced audio inputs can be embedded in one CATx input and two HDMI video inputs respectively. Provides two groups of audio outputs (balanced audio and digital SPDIF audio) for audio de-embedding. Supports MIX audio input and its volume control. Supports HDMI output, CATx output audio control. Multiple control options: Controllable via RS-232 local and pass-through, IR local and pass-through, TCP/IP, relay, CEC and on OSD. Sign in to view prices
Modular Matrix Switcher – 4K Seamless, I/O Auto Detect, 16-Port Comprehensive signal card compatibility: HDMI/DVI/CATx Extension. Automatically recognizes input/output signal cards. Powerful EDID management. UPnP enables quick-connection to GUI. HDCP Compliant. Controllable via front panel buttons, IR, RS-232 and TCP/IP. Adjustable output resolution. Online firmware upgrade via USB port. Sign in to view prices
